Baker AutoPAC L - 15 GPM - 24000 Series
Baker AutoPAC L - 15 GPM - 24000 Series

Baker AutoPAC L - 15 GPM - 24000 Series

Horsepower: 1/2
Control: Pressure Switch
Phase: Two Wire Single Phase

Product variant with selected options does not exist!
MAP
$2,325.83
SKU: 6630-704
Weight : 41.0 lb
Free Shipping $499 or more
Need it fast? Call for same-day shipping options: 281.664.8000
Description

Baker AutoPAC Variable Frequency Drive submersible pump assembly. L - 15 GPM (24000 Series Stainless Steel). Complete system includes AutoDRIVE VFD, submersible pump, and motor. All models operate at 230V 60 Hz. Available in Two Wire Single Phase, Three Wire Single Phase, and Three Wire Three Phase configurations with Pressure Switch or Transducer control.

Technical Details
Two Wire Single Phase, w/Pressure Switch
Part No. Model No. HP Volt Wt.
6630-704 24050L2-APS 1/2 230V 41
6630-714 24075L2-APS 3/4 230V 44
6630-725 24100L2-APS 1 230V 50
6630-737 24150L2-APS 1 1/2 230V 56
Two Wire Single Phase, w/Transducer
Part No. Model No. HP Volt Wt.
6630-699 24050L2-APT 1/2 230V 41
6630-709 24075L2-APT 3/4 230V 44
6630-719 24100L2-APT 1 230V 50
6630-731 24150L2-APT 1 1/2 230V 56
Three Wire Single Phase, w/Pressure Switch
Part No. Model No. HP Volt Wt.
6630-748 24050L3-APS 1/2 230V 39
6630-758 24075L3-APS 3/4 230V 41
6630-769 24100L3-APS 1 230V 49
6630-781 24150L3-APS 1 1/2 230V 55
6630-791 24200L3-APS 2 230V 57
Three Wire Single Phase, w/Transducer
Part No. Model No. HP Volt Wt.
6630-743 24050L3-APT 1/2 230V 39
6630-753 24075L3-APT 3/4 230V 41
6630-763 24100L3-APT 1 230V 49
6630-775 24150L3-APT 1 1/2 230V 55
6630-786 24200L3-APT 2 230V 57
Three Wire Three Phase, w/Transducer
Part No. Model No. HP Volt Wt.
6630-858 24150L3Z-APT 1 1/2 230V 48
6630-796 24200L3Z-APT 2 230V 55
6630-800 24300L3Z-APT 3 230V 66
6630-804 24500L3Z-APT 5 230V 86
Datasheet

AutoPac Guide
