Pumptec
Pumps › Pumptec Pump Protection
Franklin Electric · QD · Remote · Plus
Pumptec Pump ProtectionSolid-State Motor Protection for Submersible Wells
Microprocessor-based fault detection that shuts down your submersible motor before damage occurs — protecting against dry wells, voltage events, sand jams, rapid cycling, and more. Three models from $358 to $968 cover 1/3 HP to 5 HP submersible installations.
$3,000+
Avg Pump Replacement
When a submersible motor burns out from a preventable fault, total cost (motor, pump end, labor) typically runs $2,500–$5,000+. Pumptec pays for itself the first time it saves your motor.
Why Pumptec
Franklin Electric Pumptec is the industry-standard solid-state pump protection device. Authorized Baker Water Systems dealer pricing through Watermain Supply.
14
Fault Conditions Covered
Pumptec Plus monitors 14 distinct fault conditions including under-voltage, over-voltage, overload, rapid cycle, dry well, and sand-jam events.
5 HP
Up to 5 HP Coverage
Pumptec Plus protects single-phase motors from 1/2 HP to 5 HP — covering virtually every residential and light-commercial submersible installation.
240 MIN
Adjustable Restart
User-selectable rest period from 1 to 240 minutes lets the well recover before automatic restart. Voltage faults restart in 2 minutes.
10–15 YR
Service Life
Solid-state design with no moving parts. Pumptec typically lasts the full life of the pump system — one purchase covers a decade-plus.
UL
UL & CSA Listed
All three Pumptec models are UL Recognized and CSA Certified for North American electrical safety standards. Suitable for outdoor installation.
What Pumptec Protects Against
Submersible pumps fail silently — hundreds of feet underground, out of sight. By the time you notice (no water, tripped breaker, or high electric bill), the motor is already burned. Pumptec catches these conditions before damage occurs.
Low Yield / Dry Well
When water level drops below the pump intake, the motor loses its cooling medium and overheats rapidly. The #1 killer of submersible motors.
Over & Under Voltage
Voltage outside ±10% of rated causes excessive current draw, winding overheating, and premature insulation breakdown. Common during storms.
Power Surges
Lightning strikes and utility switching events send destructive voltage spikes through the electrical system directly to motor windings underground.
Air / Gas Lock
Trapped air prevents water from reaching impellers, causing the motor to spin freely without the hydraulic load it needs for proper cooling.
Rapid Cycling
A waterlogged pressure tank or failed check valve causes the pump to start and stop excessively, generating heat that exceeds thermal capacity.
Sand & Mud Clogging
Abrasive particles jam the pump stages, creating an overload condition that increases current draw and generates excessive motor heat.
Broken Shaft / Coupling
Mechanical failure causes a sudden drop in motor load. Without protection, the motor free-spins at excessive RPM, destroying bearings and seals.
Worn Pump Parts
Gradually worn impellers and diffusers reduce hydraulic load, causing abnormal current patterns that accelerate further damage.
Clogged Well Screen
Mineral buildup or sediment restricts water flow to the pump, reducing cooling and creating cavitation that erodes internal components.
Pumptec Models
Three models cover the full residential and light-commercial submersible motor range. Selection depends on motor wire configuration (2-wire vs 3-wire), horsepower, and whether you need remote fault indication.
Choose Your Model
QD Pumptec
Plug-and-Play · Franklin QD Boxes
$358.10$582
Plugs directly into Franklin QD control boxes — zero tools, zero wiring. Designed exclusively for 3-wire single-phase motors from 1/3 to 1 HP. Dual-knob calibration for sensitivity and timeout. Adjustable 2–240 minute restart timer.
HP Range1/3 – 1 HP
Voltage230V Single Phase
Wire Config3-Wire Only
Baker Part6617-145
View QD Pumptec
Pumptec with Remote
Remote Fault Light · 2-Wire Compatible
$508.85$827
Adds a remote indicator light that mounts inside the home, garage, or utility room — see pump status without walking to the wellhead. Works with 2-wire and 3-wire motors. Most versatile model for smaller residential installs.
HP Range1/3 – 1½ HP
Voltage115V / 230V
Wire Config2-Wire & 3-Wire
Baker Part6617-425
View Pumptec Remote
Most Popular
Pumptec Plus
Full-Spectrum Protection · Up to 5 HP
$967.87$1,573
Flagship model with all 14 fault protections including over-voltage, overload, rapid cycle, and waterlogged tank detection. Snap Shot™ push-button calibration records your motor's exact electrical signature. Built-in 30A heavy-duty contactor.
HP Range1/2 – 5 HP
Voltage230V Single Phase
Wire Config2-Wire & 3-Wire
Baker Part6617-143
View Pumptec Plus
Why It Pays for Itself
The math on pump protection is simple. One prevented motor burnout typically saves multiples of the device cost.
Cost Comparison
- QD Pumptec: $358.10 one-time purchase. Protects 1/3–1 HP three-wire submersibles for the life of the pump system.
- Pumptec with Remote: $508.85 one-time purchase. Adds remote fault indicator for in-home monitoring; works with both wire configurations up to 1½ HP.
- Pumptec Plus: $967.87 one-time purchase. Covers 1/2–5 HP with all 14 fault conditions, Snap Shot™ calibration, and 30A built-in contactor.
- Pulling and reinstalling a submersible pump: $1,500 – $3,000+ in labor alone, before any equipment cost.
- Replacement motor (1–2 HP): $1,000 – $1,700 for parts only.
- Total submersible pump replacement: $2,500 – $5,000+ for motor, pump end, and labor combined.
- Net savings from one prevented failure: $1,500 – $4,500+ — Pumptec pays for itself many times over the first time it activates.
How to Choose the Right Pumptec
Selection comes down to four factors: motor wire configuration, horsepower, voltage, and whether you need remote fault indication.
Motor Wire Config
3-wire only? → QD Pumptec or Pumptec Plus. 2-wire? → Pumptec with Remote or Pumptec Plus. The QD model uses a plug-in connector specific to Franklin QD boxes — not compatible with 2-wire AY motors.
Motor Horsepower
1/3–1 HP? → QD Pumptec works. 1–1½ HP? → Pumptec with Remote. 1½–5 HP? → Pumptec Plus is your only option. Plus also handles 1/2 HP if you want maximum protection on smaller motors.
Voltage Supply
230V single-phase is standard for QD Pumptec and Pumptec Plus. Pumptec with Remote also handles 115V — useful for 1/2 HP and smaller installations on residential 115V circuits.
Remote Indication
Want to see pump status from inside the house? → Pumptec with Remote is the only model with a remote fault light. Useful for seasonal homes, rentals, or installs where the wellhead is far from the house.
Calibration Method
QD Pumptec uses dual-knob adjustment (estimate the threshold). Pumptec Plus uses Snap Shot™ push-button calibration that records your motor's actual baseline — more accurate, fewer false trips.
Need Maximum Protection?
Only Pumptec Plus covers all 14 fault conditions including over-voltage, overload, rapid cycling, waterlogged tank, and faulty check valve detection. The other two models cover 8 of 14.
Frequently Asked Questions
Common questions about Pumptec pump protection devices.
Can I use Pumptec with a 2-wire submersible motor?
Yes — but not the QD Pumptec. The QD model is designed exclusively for Franklin 3-wire QD control boxes. For 2-wire motors, choose either the Pumptec with Remote Reading (up to 1½ HP) or the Pumptec Plus (up to 5 HP). Baker's catalog specifically notes the QD model is NOT compatible with 2-wire AY motors.
Does Pumptec work with non-Franklin motors like Baker submersibles?
The Pumptec Plus and Pumptec with Remote Reading work with all single-phase submersible motors regardless of brand — they monitor universal electrical load patterns. The QD Pumptec, however, only works with Franklin QD control boxes due to its plug-in connector design.
What happens when Pumptec detects a fault?
Pumptec immediately shuts power to the motor and illuminates the fault indicator light. After the user-adjustable rest period (1 to 240 minutes depending on model), it automatically restarts the pump. If the fault persists, it shuts down again and repeats. For voltage faults, most models restart after a shorter 2-minute delay. You can manually reset by cycling power off for 5 seconds.
Can I use Pumptec on a jet pump?
No. Franklin Electric specifically states Pumptec is not designed for jet pumps or permanent split capacitor (PSC) surface motors. Pumptec is for submersible pump motors only. Do not use Pumptec with a pump system using a Dole flow control valve.
Will Pumptec work in a low-yield well where water cascades onto the pump?
Franklin Electric advises Pumptec is "not recommended for low yielding wells where the water cascades down onto the pump." In these conditions, the motor load pattern doesn't change predictably enough for fault detection. Consult with a well professional about alternative protection strategies for extreme low-yield applications.
Where is Pumptec installed?
All Pumptec models install above ground — either plugged into the control box (QD model) or wired in-line between power supply and motor leads (Remote and Plus models). The Pumptec Plus is rated for outdoor use and can be mounted directly at the wellhead or pressure tank location.
What's the difference between Snap Shot™ and knob calibration?
Knob calibration (QD model) uses manual dials — you're estimating the right threshold. Snap Shot™ (Pumptec Plus) records your motor's actual electrical signature under normal operation at the push of a button, then uses that precise baseline. Snap Shot™ is more accurate and produces significantly fewer false trips.
Is Watermain Supply an authorized Baker / Franklin dealer?
Yes. Watermain Supply (a DBA of E4 Industrial LLC) is an authorized Baker Water Systems dealer and carries Franklin Electric Pumptec at dealer pricing. All units ship with full manufacturer warranty.
Need Help Sizing Your Pumptec?
Tell us your motor HP, wire configuration (2-wire or 3-wire), and voltage — we'll match you to the right model and confirm pricing.
281.664.8000
