Baker AutoPAC Variable Frequency Drive submersible pump assembly. G - 40 GPM (24000 Series Stainless Steel). Complete system includes AutoDRIVE VFD, submersible pump, and motor. All models operate at 230V 60 Hz. Available in Two Wire Single Phase, Three Wire Single Phase, and Three Wire Three Phase configurations with Pressure Switch or Transducer control.
| Two Wire Single Phase, w/Pressure Switch | ||||
|---|---|---|---|---|
| Part No. | Model No. | HP | Volt | Wt. |
| 6630-814 | 24150G2-APS | 1 1/2 | 230V | 54 |
| Two Wire Single Phase, w/Transducer | ||||
|---|---|---|---|---|
| Part No. | Model No. | HP | Volt | Wt. |
| 6630-810 | 24150G2-APT | 1 1/2 | 230V | 54 |
| Three Wire Single Phase, w/Pressure Switch | ||||
|---|---|---|---|---|
| Part No. | Model No. | HP | Volt | Wt. |
| 6630-824 | 24150G3-APS | 1 1/2 | 230V | 53 |
| 6630-832 | 24200G3-APS | 2 | 230V | 54 |
| Three Wire Single Phase, w/Transducer | ||||
|---|---|---|---|---|
| Part No. | Model No. | HP | Volt | Wt. |
| 6630-820 | 24150G3-APT | 1 1/2 | 230V | 53 |
| 6630-828 | 24200G3-APT | 2 | 230V | 54 |
| Three Wire Three Phase, w/Transducer | ||||
|---|---|---|---|---|
| Part No. | Model No. | HP | Volt | Wt. |
| 6630-862 | 24150G3Z-APT | 1 1/2 | 230V | 46 |
| 6630-836 | 24200G3Z-APT | 2 | 230V | 52 |
| 6630-840 | 24300G3Z-APT | 3 | 230V | 63 |
| 6630-845 | 24500G3Z-APT | 5 | 230V | 78 |
