files/SubDrive-Connect-Utility-NEMA4_Drive-Lineup_c242c1e8-cd54-43cd-a7e3-52969291516e.jpg
03:05 AM
Included: the accessory or kit listed under the order number shown; cable lengths and sensor ranges are in the table.
Fits the drives named in the Used With column. Confirm your drive model and date code against it; several kits differ by drive date code.
Replacement parts and add-ons for Franklin SubDrive and MonoDrive constant pressure drives: pressure sensors and transducers with their cables, filters and surge capacitors, cooling fan and screen kits, relay and option boards, duplex alternator cables and tank drawdown kits.
Every option ends with the Franklin order number, so you can match the number on your existing part.
Franklin warrants these products for 1 year from the date of installation, but in no event more than 2 years from the date of manufacture. Franklin’s limited warranty does not cover performance affected by abrasive materials, corrosion due to aggressive conditions or improper voltage supply.
Source: Franklin Electric SubDrive Connect and SubDrive Utility Owner’s Manuals.
53 part numbers, grouped by Group. Open a group to see its rows.
| Item | Part No. |
|---|---|
| All N4 Model Internal Stirring Fan Kit | 225635904 |
| UT2W Fan Replacement Kit | 226115915 |
| MD/SD 75 N1 Fan Kit (3.15 in OD) | 225635905 |
| MD/SD 75 N1 Fan Kit (3.62 in OD) | 225635908 |
| MD/SD 75 N4 Fan Kit | 225635901 |
| MD XT/SD 100-150 N1 Fan Kit (3.15 in OD) | 225635907 |
| MD XT/SD 100-150 N1 Fan Kit (3.62 in OD) | 225635909 |
| MD XT/SD 100-150 N4 Fan Kit | 225635902 |
| NEMA 3R Fan Replacement Kit (SD15 and MD) | 226545901 |
| NEMA 3R Fan Replacement Kit (SD20, SD30, MDXT) | 226545902 |
| SD 2W Fan Kit | 225635910 |
| SD 300 External Fan Kit | 225635903 |
| SD15/MD Connect Fan Kit | 226545904 |
| SD20/30/MDXT Connect Fan Kit | 226545905 |
| SD50 Fan Kit | 226545903 |
| Item | Part No. |
|---|---|
| Duplex Alternator Cable Kit 10 ft | 226895901 |
| Duplex Alternator Cable Kit 100 ft | 226895903 |
| Duplex Alternator Cable Kit 50 ft | 226895902 |
| SD Direct Cable Burial Kit - 100 ft | 225800903 |
| SD Direct Cable Burial Kit - 10 ft | 225800901 |
| SD Direct Cable Burial Kit - 30 ft | 225800902 |
| Item | Part No. |
|---|---|
| Conduit Grounding Kit | 224471901 |
| MD/SD Surge Capacitor | 225199901 |
| MD Test Drive Kit | 225260901 |
| SD 2W, SD300 and N4 Drawdown Kit | 225770901 |
| SD N4 Heatsink Cover Kit | 225805901 |
| SD N4 Auxiliary Relay Board Kit (Except SD300) | 225755901 |
| SD N4 Option Card Kit (Except SD300) | 225880901 |
| Item | Part No. |
|---|---|
| Screen Replacement Kit | 226115920 |
| Screen Replacement Kit | 575214902 |
| Item | Part No. |
|---|---|
| MD/SD AMR Input Filter Kit | 226030901 |
| MD/SD IGF Input Filter Kit | 226035901 |
| MD/SD Input Filter | 225198901 |
| MD/SD Output Filter (Except SD300) | 225300901 |
| MD/SD System Filter | 225650901 |
| SD 2W Air Filter Kit | 225835901 |
| SD50 Air Filter Kit | 226550902 |
| Item | Part No. |
|---|---|
| Moisture Sensor Kit | 226770901 |
| Pressure Sensor Cable Kit - 100 ft | 223995902 |
| Pressure Sensor Cable Kit - 10 m | 223995905 |
| Pressure Sensor Kit | 226941901 |
| Pressure Sensor Kit SD300 | 225495901 |
| Standard Pressure Sensor Kit (25-80 PSI) | 223995901 |
| Item | Part No. |
|---|---|
| Pressure Transducer Cable Kit 10 ft | 226910901 |
| Pressure Transducer Cable Kit 100 ft | 226910904 |
| Pressure Transducer Cable Kit 150 ft | 226910905 |
| Pressure Transducer Cable Kit 25 ft | 226910902 |
| Pressure Transducer Cable Kit 50 ft | 226910903 |
| Pressure Transducer Kit 10 Bar | 226905906 |
| Pressure Transducer Kit 100 PSI | 226905902 |
| Pressure Transducer Kit 150 PSI | 226905903 |
| Pressure Transducer Kit 16 Bar | 226905907 |
| Pressure Transducer Kit 200 PSI | 226905904 |
