Franklin Electric PowerSewer Replacement Parts and Accessories

Part Type: Rails and Channels
Part: 60 in Rail Assembly - 115250960

Product variant with selected options does not exist!
$563.32
SKU: 115250960
Weight : 20.0 lb
Loading locations...
Free Shipping $499 or more
Need it fast? Call for same-day shipping options: 281.664.8000
Description
Franklin Electric · Pump Accessories
PowerSewer Parts and Accessories
Rail assemblies, float trees, C-channels, riser extensions, discharge disconnect and check valve parts, direct bury wire and the pump tree assembly for the FPS PowerSewer grinder station.
37 Part Numbers
Fits PowerSewer V4PS
60-96 in Basins
Riser Extensions
Overview

Replacement parts and accessories for the FPS PowerSewer low-pressure sewer station, listed by Franklin Electric order number, which is also the SKU.

Rail assemblies and float trees are sized to the basin height (60, 72, 84 or 96 in). The C-channel replacements are for the earlier V3PS basins; the basin retrofit assemblies convert 72, 84 and 96 in V1 and V2 basins to float control. Fiberglass riser extensions raise the rim where final grade is higher than planned.

Genuine Franklin Electric equipment, factory-new in original packaging — sold and supported by Watermain Supply, an independent industrial supplier.
Warranty: 12 months from the date of purchase.
Parts and Fit
Part Order No. Fits
60 in Rail Assembly 115250960 V4PS60
72 in Rail Assembly 115250972 V4PS72
84 in Rail Assembly 115250984 V4PS84
96 in Rail Assembly 115250996 V4PS96
Rail Adaptor, Short 2 in 115257001 PowerSewer rail
C-Channel Replacement V3PS54 115041 V3PS54 basin
C-Channel Replacement V3PS72 115043 V3PS72 basin
C-Channel Replacement V3PS84 115045 V3PS84 basin
C-Channel Replacement V3PS96 115047 V3PS96 basin
60 in Float Tree 115550960 V4PS60
72 in Float Tree 115550972 V4PS72
84 in Float Tree 115550984 V4PS84
96 in Float Tree 115550996 V4PS96
3-Float Tree, 72 in Basin 115512 72 in basin, 3-float system
3-Float Tree, 84 in Basin 115513 84 in basin, 3-float system
72 in Basin Retrofit to Float 115823 72 in basin, V1 and V2
84 in Basin Retrofit to Float 115824 84 in basin, V1 and V2
96 in Basin Retrofit to Float 115825 96 in basin, V1 and V2
Basin Cover 115246901 PowerSewer basin
6 in Fiberglass Riser 115580 PowerSewer basin extension
12 in Fiberglass Riser 115581 PowerSewer basin extension
18 in Fiberglass Riser 115582 PowerSewer basin extension
24 in Fiberglass Riser 115583 PowerSewer basin extension
Anti-Siphon Check Valve Assembly 115195 PowerSewer discharge (disconnect check ball assembly)
Disconnect Check Ball, Spring-Loaded 115186 PowerSewer discharge
Disconnect Face, Fixed PVC 115081 PowerSewer discharge disconnect
Sealing Diaphragm 115202 PowerSewer discharge disconnect
Wave Spring Seat, Grey PVC 115204 PowerSewer discharge disconnect
Wave Spring, Disconnect 115205 PowerSewer discharge disconnect
1-1/4 in Discharge Pipe 115091 PowerSewer discharge
Discharge Pipe Kit Assembly 115220 PowerSewer discharge
Ball Valve 1-1/4 in PVC 940051 PowerSewer discharge; Spears
12/4 Direct Bury Wire, 50 ft 115791 Pump power, panel to basin
12/4 Direct Bury Wire, 100 ft 115792 Pump power, panel to basin
18/7 Direct Bury Wire, 50 ft 115793 Float control, panel to basin
18/7 Direct Bury Wire, 100 ft 115794 Float control, panel to basin
IGP-M231-10 Pump Tree Assembly 515551101 PowerSewer only

Source: Franklin Electric price list 996791 (June 2026), PowerSewer section, and FPS Wastewater Catalog M5276 (09-25).

Before You OrderConfirm the basin height and version from the basin label before ordering rails, float trees or C-channels. Plate 115704 is held pending clarification from Franklin.
For engineering-led sizing and selection support or a factory submittal, email sales@watermainsupply.com or call 1-888.510.4036.
