Franklin Electric replacement pump motor
Franklin Electric replacement pump motor

Franklin Electric 56J Replacement Motors

Model: ASB818
HP - Voltage: 3 HP - 208-230V 1Ph
Enclosure: ODP

Product variant with selected options does not exist!
$1,974.49
SKU: ASB818
Weight : 36.0 lb
Free Shipping $499 or more
Need it fast? Call for same-day shipping options: 281.664.8000
Description
Franklin Electric · Replacement Motor
56J Threaded Shaft Replacement Motors
56J threaded shaft motors Franklin Electric lists for the 3 HP FBSE and the FBSEF self-priming pumps.
5 Motors
56J Threaded Shaft
1-1/2 to 3 HP
ODP and TEFC
Overview

Franklin Electric lists each of these 56J motors against one pump: the two open drip-proof 3 HP motors are for the FBSE-300-S and FBSE-300-T, and the three TEFC motors are for the FBSEF-150-SE, FBSEF-200-SE and FBSEF-300-SE. NEMA 56J frame, threaded shaft, 3600 RPM.

The pump they drive is here: FBSE self-priming pumps, and its wet end is here: FBSE pump end kits.

Genuine Franklin Electric equipment, factory-new in original packaging — sold and supported by Watermain Supply, an independent industrial supplier.
Motors
Order No. Franklin lists it for Horsepower Phase Voltage Enclosure Full Load Amps Weight
ASB818 FBSE-300-S 3 HP 1 208-230V ODP 14.8-13.5 36 lb
218781 FBSE-300-T 3 HP 3 208-230/460V ODP 8.5-8/4 42 lb
EU09 FBSEF-150-SE 1-1/2 HP 1 115/208-230V TEFC 16.6/9-8.3 40 lb
EU11 FBSEF-200-SE 2 HP 1 208-230V TEFC 9.6-9.0 42 lb
EU12 FBSEF-300-SE 3 HP 1 208-230V TEFC 13.7-13 47 lb
Confirm Before OrderingA 56J motor has a threaded shaft and does not interchange with a 56C keyed shaft motor. Send us the pump model and the old motor nameplate and we will confirm it.
For engineering-led sizing and selection support or a factory submittal, email sales@watermainsupply.com or call 1-888.510.4036.
