Style 411 - Steel Coupling - Cast & Ductile Iron Pipe

Typically ships in 7-10 business days

Product Features:

• A bolted sleeve type coupling for joining plain end pipe of the same diameters.
• Meets applicable AWWA C219 Standards
• Allows for limited expansion and contraction
• Will dampen vibration to reduce pipe fatigue
• Easy to install no special pipe end preparation required
• Available in a wide variety of pipe O.D. sizes and sleeve lengths
• Most sizes will accommodate anchor studs to restrain the joints
• Can be custom made to fit odd O.D.s or other unusual applications
• Provided with or without pipe stops to accommodate customer needs

Materials:

• Has good deflection capabilities allows change in piping direction without the need of elbows bends
• Steel sizes built to specific O.D. and Ductile Iron sizes are built with range to accommodate the variances in Ductile Iron pipe O.D.s Application
• Joining plain end pipe without the need for welding or special pipe fittings. Pipe Applications
• All Types. HDPE requires use of stiffeners.

Specifications:

• Nominal sizes: 2" through 96"
• Working pressure: per design (typical 150–250 PSI)
• Body: Fabricated Carbon Steel with Flexi-Coat Epoxy finish
• Gaskets: Nitrile (Buna-N), wedge-shaped
• Bolts: High-strength low-alloy oval-neck track-head
• Meets applicable AWWA C219 Standards
