All Smith-Blair products are Made to Order and Non-Returnable

Items typically shipped in 5 - 10 business days

Price on Application - Contact us for pricing

Product Features:

• Double End expansion joint with 10" expansion
• Available in plain ends beveled for welding or flanged ends
• Options with or without slip pipe and limit rods
• Hard chrome plated slip pipes are standard
• Comes with alloy bolts and nuts
• Nominal sizes 3" through 24"

Materials:

• BODY Carbon Steel with Epoxy Coating
• SLIP PIPE Hard Chrome Plated (standard)
• GASKET Nitrile (Buna-N)
• BOLTS AND NUTS Alloy Steel

Specifications:

• Nominal Sizes: 3" through 24"
• Expansion: 10" (double end)
• End Types: Plain beveled for welding or flanged
• Configurations: With/without slip pipe, with/without limit rods

Standards & Approvals:

• Manufactured to Smith-Blair engineering standards
• Hard chrome plated slip pipes standard

Installation Steps:

• Verify pipe alignment and expansion joint configuration before installation
• For welded ends, prepare pipe ends per welding code requirements
• For flanged ends, align bolt holes and install gasket
• Install limit rods if equipped, adjusting to the required expansion range
• Torque all bolts to recommended values
• Pressure test the joint before placing into service

Important Notes:

• Price on Application - contact Watermainsupply for current pricing
• Verify expansion requirements before selecting configuration
• Follow all applicable safety procedures and local codes

Style 612 Datasheet
