8600SW Shallow-Well Irrigation & Transfer Pump - to 65 GPM, 1/2-1 HP | A.Y. McDonald

Horse Power: 1/2
Voltage & Phase: 115 / 230 / 1
Model No.: 8650SW

Product variant with selected options does not exist!
MAP
$709.40
SKU: 6165-006
Weight : 40.0 lb
Free Shipping $499 or more
Need it fast? Call for same-day shipping options: 281.664.8000
Description

The convertible centrifugal pump is ideal for lawn sprinkling, garden irrigation, pool filling, draining, cooling towers, and other water transfer applications. The square flange construction has a high service factor rating for continuous operation. The 8600SW pump has a capacity to 65 gallons per minute (GPM), and requires no maintenance.

Ā

Technical Details
  • Features:
  • Self-priming under normal conditions
  • Time proven 5/8ā€ mechanical seal
  • Pressure to 40 PSI / 92 feet head
  • For shallow wells
  • lakes
  • streams
  • or booster systems
Datasheets

8600SW Spec Sheet

Performance

Model
No.		 HP Suction
Lift - FT.		 Capacities in GPM at Discharge Pressure Max. Shut
off pressure
PSI / FT.
5# / 12' 10# / 23' 15# / 35' 20# / 46' 25# / 58' 30# / 69' 35# / 81'
8650SW 1/2 10 52 49.5 47 39.5 25 10.8 -- 34# / 78'
20 46.5 45.5 40.5 28 11.5 -- -- 30# / 69'
8670SW 3/4 10 60 60 57.8 56 51.5 40 Ā  38# / 88'
20 52 52 52 50 41 19.3 Ā  34# / 78'
8610SW 1 10 65 65 62.8 60.8 57 50 41.5 42# / 97'
20 54 54 53.5 52.5 48 41 26

38# / 88'

Ā

Models

Part No. Model No. HP Volts Pipe Sizes
Suction		 Pipe Sizes
Discharge		 Ship WT. (lbs.)
6165-006 8650SW 1/2 115 / 230 1 1/4" 1" 40#
6165-007 8670SW 3/4 230 / 115 1 1/4" 1" 42#
6165-008 8610SW 1 230 / 115 1 1/4" 1" 46#
- Suction Pipe = 1 1/4" NPT. For best results increase to 2" NPT within 6" of pump intake.
- Discharge Pipe = 1" NPT. For best results increase to 1 1/2" NPT within 6" of pump outlet using priming plug opening.
- Maximum allowable operating pressure = 100 PSIG (as a booster pump, for example).
NOTE: Standard 8600 series pumps, with pressure switch, may also be used with these applications and if the 3/4" top discharge tapping is increased to 1 1/2 NPT similar, but slightly less, capacity will be obtained.
