Replacement hardware for Smith-Blair OMNI couplings (441, 442), end caps (482) and the 912 OMNI flanged coupling adapter. Most 2 to 8 in OMNI couplings take 5/8 x 8 in oval neck bolts; 10 to 16 in take 5/8 x 9 in, with longer bolts on reducing and long-sleeve builds. The 912 uses ductile iron cross bolts and tee bolts plus flange bolts or studs by size.
Pick the type and size, then the finish; the part number shows in the last option. Bolt and nut counts per coupling are on the Smith-Blair selection chart (one nut per bolt on OMNI couplings); the 912 takes three nuts per stud and one per flange bolt. Spring washers are for approved HDPE products, two per bolt.
Included: Low-cost items are sold in packs (2 to 50 pieces); the pack size shows in the last option with the part number. Coupling bolt counts are on the Smith-Blair datasheet for each style.
Smith-Blair warrants its products to be free of defects in materials and workmanship for one year from the date of shipment by Smith-Blair. Dated proof of purchase, such as a bill of sale, is required to establish eligibility. Smith-Blair will repair or, at its option, replace a defective product; the product is returned to the factory or warehouse Smith-Blair designates.
| Alloy steel (-005) | High-strength low-alloy steel per AWWA C111/A21.11, heavy semi-finished hex nuts |
| Electro-galvanized (-001, -021) | Carbon steel, electro-galvanized with dichromate seal |
| Stainless (-002, -202) | Type 304 stainless steel |
| Ductile iron (-037) | 912 cross bolts and tee bolts, ductile iron |
| Other codes | -023, -205, -224 and -302 per Smith-Blair specification |
Materials subject to change by the manufacturer.
| Type - Size - Finish | Fits Smith-Blair style |
|---|---|
| Oval Neck Bolt - 5/8 x 4-1/2 in - 304 Stainless Steel | 441, 442, 482 and 912 |
| Oval Neck Bolt - 5/8 x 4-1/2 in - Alloy Steel | 441, 442, 482 and 912 |
| Oval Neck Bolt - 5/8 x 6 in - 304 Stainless Steel | 441, 442, 482 and 912 |
| Oval Neck Bolt - 5/8 x 6 in - Alloy Steel | 441, 442, 482 and 912 |
| Oval Neck Bolt - 5/8 x 8 in - 304 Stainless Steel | 441, 442, 482 and 912 |
| Oval Neck Bolt - 5/8 x 8 in - Alloy Steel | 441, 442, 482 and 912 |
| Oval Neck Bolt - 5/8 x 8 in - Code -023 | 441, 442, 482 and 912 |
| Oval Neck Bolt - 5/8 x 9 in - 304 Stainless Steel | 441, 442, 482 and 912 |
| Oval Neck Bolt - 5/8 x 9 in - Alloy Steel | 441, 442, 482 and 912 |
| Oval Neck Bolt - 5/8 x 9 in - Code -023 | 441, 442, 482 and 912 |
| Oval Neck Bolt - 5/8 x 10-1/2 in - 304 Stainless Steel | 441, 442, 482 and 912 |
| Oval Neck Bolt - 5/8 x 10-1/2 in - Alloy Steel | 441, 442, 482 and 912 |
| Oval Neck Bolt - 5/8 x 10-1/2 in - Code -023 | 441, 442, 482 and 912 |
| Oval Neck Bolt - 5/8 x 11 in - 304 Stainless Steel | 441, 442, 482 and 912 |
| Oval Neck Bolt - 5/8 x 11 in - Alloy Steel | 441, 442, 482 and 912 |
| Oval Neck Bolt - 5/8 x 13-1/2 in - 304 Stainless Steel | 441, 442, 482 and 912 |
| Oval Neck Bolt - 5/8 x 13-1/2 in - Alloy Steel | 441, 442, 482 and 912 |
| Oval Neck Bolt - 5/8 x 15 in - 304 Stainless Steel | 441, 442, 482 and 912 |
| Oval Neck Bolt - 5/8 x 15 in - Alloy Steel | 441, 442, 482 and 912 |
| Oval Neck Bolt - 5/8 x 17 in - 304 Stainless Steel | 441, 442, 482 and 912 |
| Oval Neck Bolt - 5/8 x 17 in - Alloy Steel | 441, 442, 482 and 912 |
| Oval Neck Bolt - 5/8 x 17 in - Code -023 | 441, 442, 482 and 912 |
| Oval Neck Bolt - 5/8 x 19-1/2 in - Alloy Steel | 441, 442, 482 and 912 |
| Oval Neck Bolt - 5/8 x 27-1/2 in - Alloy Steel | 441, 442, 482 and 912 |
| Square Neck Bolt - 3/8 x 3 in - 304 Stainless Steel | 441, 442, 482 and 912 |
| Square Neck Bolt - 3/8 x 3 in - Electro-Galvanized | 441, 442, 482 and 912 |
| Square Neck Bolt - 7/16 x 4 in - 304 Stainless Steel | 441, 442, 482 and 912 |
| Square Neck Bolt - 7/16 x 4 in - Electro-Galvanized | 441, 442, 482 and 912 |
| Square Neck Bolt - 1/2 x 7 in - 304 Stainless Steel | 441, 442, 482 and 912 |
| Square Neck Bolt - 1/2 x 7 in - Electro-Galvanized | 441, 442, 482 and 912 |
| Square Neck Bolt - 5/8 x 17 in - 304 Stainless Steel | 441, 442, 482 and 912 |
| Square Neck Bolt - 5/8 x 17 in - Alloy Steel | 441, 442, 482 and 912 |
| Bolt - 5/8 x 6-7/8 in - 304 Stainless Steel | 441, 442, 482 and 912 |
| Bolt - 5/8 x 6-7/8 in - Alloy Steel | 441, 442, 482 and 912 |
| Bolt - 3/4 x 9-1/4 in - Alloy Steel | 441, 442, 482 and 912 |
| Bolt - 3/4 x 9-1/4 in - Stainless Steel | 441, 442, 482 and 912 |
| Bolt - 3/4 x 11-1/4 in - Alloy Steel | 441, 442, 482 and 912 |
| Bolt - 3/4 x 11-1/4 in - Stainless Steel | 441, 442, 482 and 912 |
| Cross Bolt - 5/8 x 7 in - Ductile Iron | 441, 442, 482 and 912 |
| Cross Bolt - 3/4 x 8 in - Ductile Iron | 441, 442, 482 and 912 |
| Cross Bolt - 7/8 x 9 in - Ductile Iron | 441, 442, 482 and 912 |
| Tee Bolt - 5/8 x 3 in - Ductile Iron | 441, 442, 482 and 912 |
| Tee Bolt - 3/4 x 3-1/4 in - Ductile Iron | 441, 442, 482 and 912 |
| Tee Bolt - 7/8 x 3-3/4 in - Ductile Iron | 441, 442, 482 and 912 |
| Flange Bolt - 5/8 x 3 in - 304 Stainless Steel | 441, 442, 482 and 912 |
| Flange Bolt - 5/8 x 3 in - Electro-Galvanized | 441, 442, 482 and 912 |
| Flange Bolt - 3/4 x 3-1/4 in - 304 Stainless Steel | 441, 442, 482 and 912 |
| Flange Bolt - 3/4 x 3-1/4 in - Electro-Galvanized | 441, 442, 482 and 912 |
| Flange Bolt - 7/8 x 3-3/4 in - 304 Stainless Steel | 441, 442, 482 and 912 |
| Flange Bolt - 7/8 x 3-3/4 in - Electro-Galvanized | 441, 442, 482 and 912 |
| Flange Stud - 5/8 x 7 in - 304 Stainless Steel | 441, 442, 482 and 912 |
| Flange Stud - 5/8 x 7 in - Electro-Galvanized | 441, 442, 482 and 912 |
| Flange Stud - 3/4 x 8 in - 304 Stainless Steel | 441, 442, 482 and 912 |
| Flange Stud - 3/4 x 8 in - Electro-Galvanized | 441, 442, 482 and 912 |
| Flange Stud - 7/8 x 9 in - 304 Stainless Steel | 441, 442, 482 and 912 |
| Flange Stud - 7/8 x 9 in - Electro-Galvanized | 441, 442, 482 and 912 |
| Stud - 5/8 x 27-1/2 in - 304 Stainless Steel | 441, 442, 482 and 912 |
| Heavy Hex Nut - 3/8 in - 304 Stainless Steel | 441, 442, 482 and 912 |
| Heavy Hex Nut - 3/8 in - Electro-Galvanized | 441, 442, 482 and 912 |
| Heavy Hex Nut - 7/16 in - 304 Stainless Steel | 441, 442, 482 and 912 |
| Heavy Hex Nut - 7/16 in - Electro-Galvanized | 441, 442, 482 and 912 |
| Heavy Hex Nut - 1/2 in - 304 Stainless Steel | 441, 442, 482 and 912 |
| Heavy Hex Nut - 1/2 in - Electro-Galvanized | 441, 442, 482 and 912 |
| Heavy Hex Nut - 5/8 in - 304 Stainless Steel | 441, 442, 482 and 912 |
| Heavy Hex Nut - 5/8 in - Alloy Steel | 441, 442, 482 and 912 |
| Heavy Hex Nut - 5/8 in - Code -205 | 441, 442, 482 and 912 |
| Heavy Hex Nut - 5/8 in - Code -224 | 441, 442, 482 and 912 |
| Heavy Hex Nut - 5/8 in - Electro-Galvanized | 441, 442, 482 and 912 |
| Heavy Hex Nut - 3/4 in - 304 Stainless Steel | 441, 442, 482 and 912 |
| Heavy Hex Nut - 3/4 in - Alloy Steel | 441, 442, 482 and 912 |
| Heavy Hex Nut - 3/4 in - Electro-Galvanized | 441, 442, 482 and 912 |
| Heavy Hex Nut - 7/8 in - 304 Stainless Steel | 441, 442, 482 and 912 |
| Heavy Hex Nut - 7/8 in - Alloy Steel | 441, 442, 482 and 912 |
| Heavy Hex Nut - 7/8 in - Electro-Galvanized | 441, 442, 482 and 912 |
| Flat Washer - 7/16 in - 304 Stainless Steel | 441, 442, 482 and 912 |
| Flat Washer - 7/16 in - Electro-Galvanized | 441, 442, 482 and 912 |
| Flat Washer - 5/8 in - 304 Stainless Steel | 441, 442, 482 and 912 |
| Flat Washer - 5/8 in - Electro-Galvanized | 441, 442, 482 and 912 |
| Flat Washer - 3/4 in - 304 Stainless Steel | 441, 442, 482 and 912 |
| Flat Washer - 3/4 in - Electro-Galvanized | 441, 442, 482 and 912 |
| Spring Washer - 1/2 in - 304 Stainless Steel | 441, 442, 482 and 912 |
| Spring Washer - 5/8 in - HDPE Saddles - 304 Stainless Steel | 441, 442, 482 and 912 |
| Spring Washer - 5/8 in - 304 Stainless Steel | 441, 442, 482 and 912 |
| Spring Washer - 3/4 in - 304 Stainless Steel | 441, 442, 482 and 912 |
From the Smith-Blair 2025 price book component selection charts.
