Replacement body, follower flange and flange O-ring for the Smith-Blair Style 912 OMNI flanged coupling adapter. One body covers every pipe OD of its nominal size, with bolt circle and spacing to ANSI 125/150 lb drilling; the follower flange and an OMNI gasket set the pipe OD. Followers are color-coded: red for iron pipe size OD, blue for ductile OD, gray for asbestos cement OD.
Pick the nominal size and OD range, then the component; the part number shows in the last option. The pipe gasket is in the OMNI Coupling Gasket listing; cross bolts, tee bolts and studs are in the hardware listing.
Included: One component as selected.
Smith-Blair warrants its products to be free of defects in materials and workmanship for one year from the date of shipment by Smith-Blair. Dated proof of purchase, such as a bill of sale, is required to establish eligibility. Smith-Blair will repair or, at its option, replace a defective product; the product is returned to the factory or warehouse Smith-Blair designates.
| Body | Ductile iron per ASTM A536 |
| Follower flange | Ductile iron per ASTM A536 |
| Flange O-ring | Nitrile |
| Finish | Flexi-Coat fusion-bonded epoxy |
Materials subject to change by the manufacturer.
| Nominal Size - OD Range - Component | Fits Smith-Blair style |
|---|---|
| 3 in - 2.85-4.14 in OD - Body | 912 |
| 3 in - 2.85-3.62 in OD - Follower Flange | 912 |
| 3 in - 3.80-4.14 in OD - Follower Flange | 912 |
| 3 in - 2.85-4.14 in OD - Flange O-Ring | 912 |
| 4 in - 4.00-5.10 in OD - Body | 912 |
| 4 in - 4.00-4.50 in OD - Follower Flange | 912 |
| 4 in - 4.46-4.86 in OD - Follower Flange | 912 |
| 4 in - 4.80-5.10 in OD - Follower Flange | 912 |
| 4 in - 4.00-5.10 in OD - Flange O-Ring | 912 |
| 6 in - 6.00-7.20 in OD - Body | 912 |
| 6 in - 6.00-6.96 in OD - Follower Flange | 912 |
| 6 in - 6.90-7.20 in OD - Follower Flange | 912 |
| 6 in - 6.00-7.20 in OD - Flange O-Ring | 912 |
| 8 in - 8.00-9.40 in OD - Body | 912 |
| 8 in - 8.00-9.11 in OD - Follower Flange | 912 |
| 8 in - 9.05-9.40 in OD - Follower Flange | 912 |
| 8 in - 8.00-9.40 in OD - Flange O-Ring | 912 |
| 10 in - 10.00-11.95 in OD - Body | 912 |
| 10 in - 10.00-10.75 in OD - Follower Flange | 912 |
| 10 in - 11.10-11.60 in OD - Follower Flange | 912 |
| 10 in - 11.65-11.95 in OD - Follower Flange | 912 |
| 10 in - 10.00-11.95 in OD - Flange O-Ring | 912 |
| 12 in - 12.00-14.20 in OD - Body | 912 |
| 12 in - 12.00-12.75 in OD - Follower Flange | 912 |
| 12 in - 13.20-13.75 in OD - Follower Flange | 912 |
| 12 in - 13.90-14.20 in OD - Follower Flange | 912 |
| 12 in - 12.00-14.20 in OD - Flange O-Ring | 912 |
From the Smith-Blair 2025 price book component selection charts.
