Replacement end cap body for the Smith-Blair Style 482 OMNI cast line cap. It seats one OMNI gasket and one follower flange on the pipe end.
Pick the nominal size; the part number shows in the last option.
Included: The end cap body only. The 482 uses the largest gasket within its nominal size, one follower and its bolts. Thrust restraint is required whenever the line is in service.
Smith-Blair warrants its products to be free of defects in materials and workmanship for one year from the date of shipment by Smith-Blair. Dated proof of purchase, such as a bill of sale, is required to establish eligibility. Smith-Blair will repair or, at its option, replace a defective product; the product is returned to the factory or warehouse Smith-Blair designates.
| End cap body | Ductile iron per ASTM A536 |
| Finish | Flexi-Coat fusion-bonded epoxy |
Materials subject to change by the manufacturer.
| Nominal Size - OD Range | Fits Smith-Blair style |
|---|---|
| 2 in - 2.34-2.63 in OD | 482 |
| 2-1/2 in - 2.65-2.88 in OD | 482 |
| 3 in - 2.85-4.14 in OD | 482 |
| 4 in - 4.00-5.45 in OD | 482 |
| 6 in - 6.00-7.65 in OD | 482 |
| 8 in - 8.00-9.85 in OD | 482 |
| 10 in - 10.00-12.20 in OD | 482 |
| 12 in - 12.00-14.40 in OD | 482 |
From the Smith-Blair 2025 price book component selection charts.
