Dresser TX3 Wide Range Flanged Adapter

Nominal Size - OD Range: 2 in - 2.10-3.03 in OD
Part No.: TX3030300000FA

Product variant with selected options does not exist!

Price
$629.09
Coupon 5% off applied automatically in your cart. No code needed.
SKU: TX3030300000FA
Weight : 21.0 lb
Loading locations...
Free Shipping $499 or more
Skip the chatbot. Talk to an expert.
1-888.510.4036 · Same-day shipping available
Description
Dresser · Flanged Adapter
TX3 Wide Range Flanged Adapter
TX3 wide range flanged adapter, 2 in to 12 in.
TX3 Wide Range Gasket
Fusion Bonded Epoxy Coated
NSF 61
21-61 lb Weight
Overview

The TX3 flanged adapter brings the TX3 wide range dual layer gasket to a flanged connection, joining plain-end pipe to a flange.

Application: Connecting plain-end water pipe to flanged valves and fittings.

What Ships and What It Needs to Run

Included: flanged adapter with gasket and drawbolts.

Genuine Dresser equipment, factory-new in original packaging — sold and supported by Watermain Supply, an independent industrial supplier.
12-Month Dresser Warranty

Covered for 12 months from the date of purchase under Dresser’s published warranty terms.

Working Pressure

Pressure rating per the product label; confirm with us before specifying.

Source: TPS TX3 literature. The rating on the product label is the actual rating of each part.

Sizes
Nominal Size - OD Range
2 in - 2.10-3.03 in OD
3 in - 3.10-4.20 in OD
4 in - 4.45-5.61 in OD
6 in - 6.56-7.65 in OD
8 in - 8.54-9.84 in OD
10 in - 10.64-11.84 in OD
10 in OS - 11.01-12.26 in OD
12 in - 12.62-13.66 in OD
12 in OS - 13.14-14.45 in OD

Sizes as listed in Dresser’s 2026 price lists; the picker shows the part number for each build.

Before You Order. Measure the pipe OD and confirm the flange drilling. Anchor the pipe: this product seals but does not restrain, and Dresser requires the pipe joint to be anchored wherever pull-out can occur. Non-stock Dresser parts are not returnable without Dresser’s authorization, and ship time is confirmed when you order. Custom builds (other sizes, widths, gaskets or materials) are available: email sales@watermainsupply.com with the pipe OD, material and line content.
For engineering-led sizing and selection support or a factory submittal, email sales@watermainsupply.com or call 1-888.510.4036.
© Watermain Supply — A division of E4 Industrial LLC
Data Sheet
Videos

Product videos are being added to this listing. For a walkthrough in the meantime, email sales@watermainsupply.com.
