Dresser Style 711 Line Cap - Seal and Restraint, Steel or PE Gas Pipe

Nominal Size - OD: 2 in - 2.38 in OD
Pipe - Part No.: Steel - 0711-9377-202

Product variant with selected options does not exist!

Price
$360.88
Coupon 5% off applied automatically in your cart. No code needed.
SKU: 0711-9377-202
Weight : 13.0 lb
Loading locations...
Free Shipping $499 or more
Skip the chatbot. Talk to an expert.
1-888.510.4036 · Same-day shipping available
Description
Dresser · Gas Coupling
Style 711 Line Cap
Seal and restraint line cap for steel and PE gas mains, 2 in to 12 in.
150 PSI Max Working Pressure
Seal and Restraint, DOT 192.281(e)
ASTM F1948 Category 1
Natural Gas Service
Steel, PE and Cast Iron Pipe
13-140 lb Weight
Overview

The Style 711 Line Cap closes off the end of a steel or polyethylene gas main with the same compression seal and grip-ring restraint as the 711 coupling, so the cap holds against pullout without welding.

Application: Capping live or abandoned steel and PE gas main ends.

  • Assembled stab design: little or no disassembly in the ditch
  • Metallic grip mechanism locks the pipe against pullout
  • PE pipe needs the matching color-coded insert stiffener
What Ships and What It Needs to Run

Included: line cap, follower, gasket, grip ring, bolts and nuts, assembled.

Also needed: insert stiffener for PE pipe, sized to the pipe SDR (sold separately).

Genuine Dresser equipment, factory-new in original packaging — sold and supported by Watermain Supply, an independent industrial supplier.
12-Month Dresser Warranty

Covered for 12 months from the date of purchase under Dresser’s published warranty terms.

Working Pressure

Line caps are rated 150 PSI in the Style 711 brochure.

Source: Dresser Style 711 Bolted Coupling Brochure (2021). The rating on the product label is the actual rating of each part.

Materials Specifications
Grip rings 4140 carbon steel, slotted, for pipe restraint
Gaskets Armored pinned gaskets, conductive for cathodic protection
PE pipe Insert stiffener required, color-coded by SDR
Compliance DOT 192.281(e), ASTM F1948 Category 1

Source: Dresser Style 711 Bolted Coupling Brochure (2021).

Sizes
Nominal Size - OD Pipe
2 in - 2.38 in OD Steel, PE SDR 11
3 in - 3.50 in OD Steel, PE SDR 11
4 in - 4.50 in OD Steel, PE SDR 11.5
6 in - 6.63 in OD Steel, PE SDR 11
8 in - 8.63 in OD Steel
10 in - 10.75 in OD Steel
12 in - 12.75 in OD Steel

Sizes as listed in Dresser’s 2026 price lists; the picker shows the part number for each build.

Installation Notes
  • Mark the pipe and stab it into the fitting to the full stab depth.
  • On PE pipe, install the correct-SDR Dresser insert stiffener (or one qualified to DOT 192.283(b)) in every PE pipe end.
  • Read the Dresser installation instructions and warnings before installing.

Source: Dresser Gas Product Selection Guide (NGS-DPS-015), product warnings.

Before You Order. Confirm pipe OD and, for PE, the SDR, so the right grip ring and insert stiffener are supplied. Non-stock Dresser parts are not returnable without Dresser’s authorization, and ship time is confirmed when you order. Custom builds (other sizes, widths, gaskets or materials) are available: email sales@watermainsupply.com with the pipe OD, material and line content.
For engineering-led sizing and selection support or a factory submittal, email sales@watermainsupply.com or call 1-888.510.4036.
