NC Series Base Elbows and Rail Accessories
Base elbows, bolt-on elbows, lift-out flanges and stainless guide rail brackets for lift-out installation of the FPS NC Series non-clog pumps.
13 Part Numbers
Fits 3NC, 4NC and 4NCH
3, 4 and 6 in Base Elbows
304 SST Brackets
Overview
Lift-out rail hardware for the FPS NC Series submersible non-clog pumps, listed by Franklin Electric order number, which is also the SKU. A base elbow bolts to the basin floor and takes the discharge; the pump slides down guide rails and seals on the elbow, so it can be pulled for service without anyone entering the wet well.
Match the base elbow to the pump discharge (3 in for the 3NC, 4 in for the 4NC and 4NCH) and the brackets to the guide rail pipe size. The upper bracket holds the rails at the top of the basin; intermediate brackets steady long rails. Rail pipe is supplied by the installer.
Genuine Franklin Electric equipment, factory-new in original packaging — sold and supported by Watermain Supply, an independent industrial supplier.
Warranty: 12 months from the date of purchase.
Parts and Fit
| Part |
Order No. |
Fits |
| 3 in Base Elbow, Flanged, Single Rail |
87109916-00 |
3NC, 3 in flanged discharge |
| 3 in Base Elbow, NPT, Single Rail |
87109788-00 |
3NC, 3 in NPT discharge |
| 3 in Horizontal Base Elbow, NPT |
115930103 |
3 in pumps; upper rail bracket not included |
| 4 in Base Elbow, Flanged |
115930104 |
4NC and 4NCH; upper rail bracket not included |
| 6 in Base Elbow |
115930135 |
6 in discharge stations |
| 3 in Bolt-On Elbow, NPT |
87109789-00 |
3NC |
| 4 in Bolt-On Elbow, FNPT |
115930126 |
4 in ANSI flange to 4 in threaded; with hardware |
| 4 in Lift-Out Flange, 3 and 4 in ANSI |
115930128 |
3 in and 4 in ANSI, double-tapped |
| 4 in Lift-Out Kit, Hardware and Gasket |
115930131 |
4 in lift-out flange |
| Upper Bracket, 0.75-1.25 in Rails |
115930105 |
3 in base elbow; 0.75, 1.00 and 1.25 in rails; SST |
| Upper Bracket, 2 in Rails |
115930106 |
4 in base elbow; 2.00 in rails; SST |
| Intermediate Bracket, 1.25 in Rails |
115930125 |
3 in base elbow; 1.25 in rails; SST |
| Intermediate Bracket, 2 in Rails |
115930109 |
4 in base elbow; 2.00 in rails, 4 in piping; SST |
Brackets are 304 stainless steel with nitrile rubber grommets. Source: FPS Wastewater Catalog M5276 (09-25), NC Series pump accessories, and Franklin Electric price list 996791 (June 2026).
Before You OrderConfirm the pump discharge size and the guide rail pipe size before ordering. Base elbows for the 4NCH base plate installation and the 4 in single-rail elbow (87101080-00) are quoted on request.
