Franklin Electric VersaJet Pro Cast Iron Shallow Well Jet Pump - NSF 372, Three Supplied Nozzles, 1/2-1 HP
Franklin Electric VersaJet Pro Cast Iron Shallow Well Jet Pump - NSF 372, Three Supplied Nozzles, 1/2-1 HP

Franklin Electric VersaJet Pro Cast Iron Shallow Well Jet Pump - NSF 372, Three Supplied Nozzles, 1/2-1 HP

Horse Power: 1/2 HP
Phase: Single-Phase
Voltage: 115/230 VAC

Product variant with selected options does not exist!
$930.34
SKU: FVJ05CI-P
Weight : 34.0 lb
Need it fast? Call for same-day shipping options: 281.664.8000
Description
Franklin Electric Jet Pump

VersaJet Pro Jet Pump
Cast Iron Shallow Well

Cast iron shallow well jet pump supplied with three nozzles, covering a range of performance needs from a single pump.

1/2 – 1 HP
Single-Phase
NSF 372 Certified
UL / CSA Listed
120 °F Max Fluid Temp
Dual Voltage 115/230 V
Overview

Built for easy customization - one VersaJet Pro covers a variety of performance needs via a patent-pending nozzle replacement system with three supplied nozzles.

Heavy-duty cast iron case with a phenolic/ceramic mechanical shaft seal for positive sealing and longevity.

Key Advantages
Revolutionary "Quick-Change" jet nozzle replacement system
Revolutionary "Quick-Change" jet nozzle replacement system allows for easy customization of the pump; performance can be quickly changed from a high pressure to high flow set-up without removing the plumbing or opening the case
Impeller (with stainless steel insert)
Impeller (with stainless steel insert), diffuser, jet nozzle, and venturi all molded with Modified PPO, a material that increases efficiency and hydraulic performance
Phenolic/Ceramic mechanical shaft seal
Phenolic/Ceramic mechanical shaft seal with nitrile elastomers and 18-8SS hardware ensures positive sealing and longevity
Heavy-duty cast iron case includes both pressure
Heavy-duty cast iron case includes both pressure and drain ports
Floating stainless steel eye seal
Floating stainless steel eye seal provides maximum performance and efficiency
Powered by high quality
Powered by high quality, industry proven, UL778 approved, indoor/outdoor square-flange single phase motors
Pressure switch installed and set at 30/50
Pressure switch installed and set at 30/50 psi
Water temperatures up to 120 °F/49 °C;
Water temperatures up to 120 °F/49 °C; 75 psi maximum working pressure
1-1/4" inlet and 1" outlet
1-1/4" inlet and 1" outlet - all models
NSF/ANSI/CAN 372 Certified
NSF/ANSI/CAN 372 Certified
Order Information
Item Model Horse Power Phase Voltage
91181005 FVJ05CI-P 1/2 HP Single-Phase 115/230 VAC
91181007 FVJ07CI-P 3/4 HP Single-Phase 115/230 VAC
91181010 FVJ1CI-P 1 HP Single-Phase 115/230 VAC
Ordering Notes

Franklin Electric publishes the same Features & Benefits list for both VersaJet and VersaJet Pro. The Pro is supplied with three nozzles in the box rather than requiring separate nozzle purchase.

Documentation & Spec Sheets
VersaJet Pro Spec Sheet
Spec Sheet — Franklin Electric published document (PDF).
Download PDF
VersaJet Pro Brochure
Brochure — Franklin Electric published document (PDF).
Download PDF
VersaJet Series Manual
Owner’s Manual — Franklin Electric published document (PDF).
Download PDF
Specification Source

Specifications, model numbers and Franklin item numbers on this page are taken from Franklin Electric published product data. Engineering-led pump sizing available — call 281.664.8000 or email sales@watermainsupply.com.
