GRUNDFOS · CME ACCESSORY
CME Pressure Sensor Kit
Grundfos CME kit for constant-pressure operation: pressure sensor, piping and fittings, matched to the CME model. 12 kits covering CME 1 to CME 25.
Pressure Sensor, Piping and Fittings
Pressure Tank on 145 PSI Max Systems
For CME 1, 3, 5, 10, 15 and 25
Grundfos Original Kit
Overview
CME pumps ship without a pressure sensor. This Grundfos kit adds the sensor, piping and fittings so the CME holds a constant discharge pressure on its own. Grundfos matches each kit to specific CME models; pick the kit that lists your pump model. A pressure tank is included for 145 PSI maximum systems only (Grundfos price list note).
| Kit part no. |
Fits CME models |
Material versions |
| 93025356 |
CME 1-2 to 1-4 and 3-2 to 3-4 |
A, I, G |
| 93025357 |
CME 1-5 to 1-7 and 3-5 to 3-7 |
A, I, G |
| 93025364 |
CME 1-8 and 3-8 |
I, G |
| 93025365 |
CME 1-9 and 3-9 |
I, G |
| 93025362 |
CME 15-1, 15-2, 25-1 and 25-2 |
A, I, G |
| 93025363 |
CME 15-3 |
A, I, G |
| 93025360 |
CME 10-1 and 10-2 |
A, I, G |
| 93025361 |
CME 10-3 and 10-4 |
A, I, G |
| 93025367 |
CME 10-5 |
I, G |
| 93025358 |
CME 5-2 to 5-4 |
A, I, G |
| 93025359 |
CME 5-5-7 |
A, I, G |
| 93025366 |
CME 5-8 |
I, G |
What Ships and What It Needs to Run
Included: the Grundfos CME kit for the models shown: pressure sensor, piping and fittings; a pressure tank where the system is rated 145 PSI maximum.
Assembly instructions: Grundfos literature 93025158.
The CME pump is sold separately.
Genuine Grundfos equipment, factory-new in original packaging — sold and supported by Watermain Supply, an independent industrial supplier.
Warranty: 24 months from date of installation, but not more than 30 months from date of manufacture (Grundfos limited warranty). Grundfos repairs or replaces its own product; costs of removal, installation and transportation are not covered, and products sold but not manufactured by Grundfos carry their own manufacturer’s warranty.
Specifications
| Specification |
Value |
| Contents |
Pressure sensor, piping and fittings (tank on 145 PSI max systems) |
| Fits |
Grundfos CME pumps, by model (table above) |
| Assembly |
Grundfos literature 93025158 |
Before You Buy — The Limits That Decide the Fit
| Check |
What decides the fit |
| Model match |
Order the kit listed for your exact CME model; kits are not interchangeable across sizes. |
| Tank |
A pressure tank is included for 145 PSI maximum systems only; confirm with us if your system is rated higher. |
Applications
Constant-pressure water supply and pressure boosting with Grundfos CME pumps.
