84000 Self-Priming Irrigation Pump
High-flow self-priming lawn sprinkler and irrigation pump, 3 or 5 HP, single or three phase, for non-potable water. Up to 173 GPM and 165 ft of head.
135-165 ft (58-71 PSI) Max Head · 132-173 GPM Max
3 or 5 HP
230V 1Ph or 208-230/460V 3Ph
Self-Priming
2-2 1/2 in Suction · 1 1/2-2 in Discharge
Brass Impeller
NEMA JM Motor, 3,500 RPM
Irrigation and Non-Potable Water
23.5-27.3 L x 13.3 H in
144-182 lb Weight
What Ships and What It Needs to Run
Included: the pump with its NEMA JM 3,500 RPM motor, brass impeller and a suction flange with flapper valve to hold the prime. The pump body is tapped for an air volume control.
Suction and discharge piping, and an air volume control where a pressure tank is used: sized to your installation and ordered separately.
Overview
Baker built the 84000 to be one of the fastest priming pumps on the market. It is a 3 or 5 HP self-priming centrifugal pump for lawn sprinkling and irrigation, delivering 87 to 146 GPM at 40 PSI from 5 ft of suction lift. The suction flange carries a flapper valve that holds the prime between runs.
For irrigation and other non-potable water. A.Y. McDonald rates the 84000 for non-potable use only; for drinking water, see the NSF-certified A.Y. McDonald jet pumps.
-
Self-priming, with a suction flange and flapper valve.
-
Brass impeller and dual ball bearing construction.
-
Single phase 230V or three phase 208-230/460V, NEMA JM motor at 3,500 RPM.
Genuine A.Y. McDonald equipment, factory-new in original packaging — sold and supported by Watermain Supply, an independent industrial supplier. Watermain Supply is an Authorized Stocking A.Y. McDonald and Baker Water Systems Distributor.
12-Month A.Y. McDonald Warranty
Covered for 1 year from the date of installation, or 2 years from the date of manufacture, whichever comes first, under A.Y. McDonald’s published limited warranty terms, as set out in the A.Y. McDonald Pumps & Accessories Price List. Components made by other manufacturers, such as the motor, carry their original manufacturer’s warranty.
Single Unit
Each 84000 runs as one pump. Size it to the zone or zones that run at once. For smaller systems, the 89000 Sprinkler Pump covers 1 to 2 HP.
Models & Ratings (60 Hz)
| Model |
Part No. |
Power |
Voltage |
Amps |
Suction |
Discharge |
Length “A” |
Catalog weight |
| 84300 |
6180-104 |
3 HP |
230V 1Ph |
14.0 (208V) · 13.2 (230V) |
2 in |
1 1/2 in |
25.50 in |
144 lb |
| 84300-3 |
6180-108 |
3 HP |
208-230/460V 3Ph |
8.3 · 7.4 · 3.7 |
2 in |
1 1/2 in |
23.50 in |
144 lb |
| 84500 |
6180-107 |
5 HP |
230V 1Ph |
24.0 (208V) · 23.7 (230V) |
2 1/2 in |
2 in |
27.25 in |
182 lb |
| 84500-3 |
6180-109 |
5 HP |
208-230/460V 3Ph |
13.5 · 12.3 · 6.2 |
2 1/2 in |
2 in |
25.75 in |
182 lb |
Three-phase amps at 208V, 230V and 460V. Source: Pumps by Baker catalog, rev 3/26, p. 281.
Specifications
| Motor |
NEMA JM, 3,500 RPM |
| Bearings |
Dual ball bearing |
| Impeller |
Brass |
| Priming |
Self-priming; suction flange with flapper valve |
| Air volume control |
Body tapped for one |
| Water |
Non-potable use only |
| App or remote connectivity |
None |
Performance — Will It Do What You Need?
Each figure is gallons per minute at the discharge pressure on the left, from the suction lift across the top, from A.Y. McDonald’s published table.
| Model |
HP |
Discharge, PSI |
Discharge head, ft |
5 ft lift |
10 ft lift |
15 ft lift |
20 ft lift |
25 ft lift |
| 84300 / 84300-3 |
3 |
20 |
46 |
123 |
120 |
108 |
98 |
70 |
| 30 |
69 |
108 |
105 |
98 |
94 |
68 |
| 40 |
92 |
87 |
82 |
76 |
70 |
62 |
| 50 |
115 |
60 |
52 |
44 |
33 |
18 |
| 84500 / 84500-3 |
5 |
20 |
46 |
162 |
160 |
151 |
140 |
98 |
| 30 |
69 |
160 |
158 |
150 |
136 |
98 |
| 40 |
92 |
146 |
141 |
136 |
130 |
96 |
| 50 |
115 |
118 |
115 |
104 |
94 |
94 |
Total head at flow, from the published curve
| Flow, GPM |
84300 (3 HP) |
84500 (5 HP) |
| 0 |
135 ft (58 PSI) |
165 ft (71 PSI) |
| 25 |
131 ft (57 PSI) |
161 ft (69 PSI) |
| 50 |
123 ft (53 PSI) |
154 ft (66 PSI) |
| 75 |
109 ft (47 PSI) |
143 ft (61 PSI) |
| 100 |
85 ft (37 PSI) |
127 ft (55 PSI) |
| 125 |
54 ft (23 PSI) |
108 ft (46 PSI) |
| 150 |
|
84 ft (36 PSI) |
Reading it: a sprinkler zone needing 40 PSI with the water 10 ft below the pump gets 82 GPM from the 3 HP and 141 GPM from the 5 HP. Every extra 5 ft of lift costs flow, most of all at the top of the table.
Zero flow is the shut-off point — a ceiling, not a working point. The curve runs to 132 GPM on the 84300 and 173 GPM on the 84500. Curve figures are digitized from the published curve in the Pumps by Baker catalog, rev 3/26, p. 282, and rounded down; the GPM table is A.Y. McDonald’s printed Performance Data, same page.
Before You Buy — The Limits That Decide the Fit
| Water |
Irrigation and other non-potable water only, per A.Y. McDonald. |
| Suction lift |
Self-priming; published to 25 ft of lift. Output falls as lift rises. |
| Maximum pressure |
Shut-off 58 PSI (3 HP) and 71 PSI (5 HP) at zero flow. |
| Power |
230V single phase, or 208-230/460V three phase. Amps per the Models table; the 5 HP single phase draws 24 A at 208V. |
| Connections |
2 in suction and 1 1/2 in discharge on the 3 HP; 2 1/2 in and 2 in on the 5 HP. |
| Pairing |
Single unit. |
Service Parts
| Part |
Code |
Use |
| 84000 Series repair parts |
84300SK, 84500SK, 84000FVA, 84000SA |
Suction kits, flapper valve, housing kits, seal sleeve and seal assembly, for pumps built from September 2020 |
